Applications
Suitable for custom processing of leather products, such as car seats, airplane seats, furniture, floor mats, handbags, footwear, and other products.
Features
1. A single machine meets the requirements for punching, embroidery, and sewing processes, allowing for versatile design.
2. Automatic upper thread tensioning device ensures tighter upper thread and uniform, beautiful stitches.
3. Uses imported double-speed sewing machine rotary hook specifically for leather.
4. Equipped with a hollow punching rod and heavy-duty punch box structure, with five different punch specifications.
5. Comes with an industrial-grade dedicated vacuum cleaner to effectively remove leather scraps.
6. Patented aluminum-magnesium alloy integrated fixture, easy to operate, cost-effective, suitable for mass production.
Parameters
| MachineModel | MFCE-MPS-2.5-2.6-2.3-1200X800-B, MFCE-MPS-2.5-2.6-2.3-900X600-B |
| Power Supply | Single-phase 220V or Three-phase 380V/50Hz |
| Display Screen | 10-inch or 15-inch Touch Screen |
| Punching Speed | 400 - 1000 RPM |
| Drive Type | Full Servo Motor |
| Sewing Speed | 400 - 1200 RPM |
| Looper Type | Motor Independent Looper |
| Embroidery Speed | 400 - 1200 RPM |
| Thread Cutting Method | Motorized Thread Cutter |
| Circular Punch | 0.8/1.0/1.2/1.5/2.0/2.5 |
| Locking Method | Motorized Locking |
| Working Area (mm) | 900x600 / 1200x800 (customizable) |
| Frame Structure | Bridge Heavy-duty Structure |
