Applications
Suitable for embroidery quilting of various types and different thicknesses of genuine leather and microfiber leather for automotive seats, aviation seats, shoe uppers, luggage, furniture, etc.
Features
1. Embroidery and sewing are integrated into one, allowing for any flower design, easily achieving complex processes with any combination of embroidery and sewing.
2. Nine-color embroidery machine head with automatic color changing, capable of rotating with a single or double shuttle, features break thread stop alarm and reverse embroidery compensation.
3. 360-degree rotating sewing machine automatic lift head, using independently driven rotating head and shuttle mechanism, with the head and shuttle capable of 360 stitch tracking, avoiding the discrepancy between the front and back stitches.
4. Micro-oil structure design at the sewing machine head, with the needle bar featuring a special DLC super-durable surface treatment.
5. Intelligent "M system upper-level software" that processes any pattern and allows for arbitrary editing of command outputs.
6. The sewing machine head can be customized with the Dukepu brand.
7. Japanese imported shuttle, with a highly wear-resistant table.
Parameters
| Pattern Reading | USB |
| The maximum sewing speed of embroidery (turns/minute) | 1200 |
| Material Fixing | Aluminum Embroidery Frame |
| format | DST |
| Air Pressure | 0.6MPa |
| Max. Power | 7.5kW |
| Control Panel | 15-inch LCD touch screen |
| Power Supply | 1P-220V/3P-380V |
| Stitch length | 0.1-12.7mm |
Models
Models | Punch bar No. | Processing area. | Installation Area (L×W×H) |
MFRCE-P-1.5-600X900-H | 5 | 600X900 | 1650mm×2000mm×1400mm |
MFRCE-P-2.5-600X900-H | 5 | 600X900 | 2950mm×2000mm×1400mm |
MFRCE-P-1.5-1200-900-H | 5 | 1200X900 | 2250mm×2000mm×1400mm |
MFRCE-P-2.5-1200X900-H | 5 | 1200X900 | 4150mm×2000mm×1400mm |
